Flyer language

Zoë

Price on request

80m x 9m
1100 ton
1995
Cummins KTA 38

Dimensions80m x 9m

Tonnage1100 ton

Year1995

EngineCummins KTA 38

Scheepsgegevens

General

Type from 1000 to 1499 tons

Vessel's name Zoë

Europe number 06002871

Shipyard Kozle (Polen)

Construction year 1995

Bijzonderheden very well maintained , 600 tons of ballast without use of the cargo space , delivrable with work , possible air draught of 4m20 with layers of containers

Dimensions (m) Length: 80, Width: 9, Draft: 2.47

Air draft (m)

Without ballast (m) 4.1

Tonnage

Max tonnage (T) 1100

Certificates

Euroclass - ADN

Cargo hold

Number of holds 1

Volume cargo hold 1750

Trim filling No

Semi double hull No

Double hull Yes

Cargo hold coaming 56,50 x 7,70m

Inner bottom Material: staal

TEU 81

Stuurhuis, Verblijven, Tanks

Wheelhouse

Manufacturer De Mooy

Material aluminium

Construction year 2003

Elevating Yes

Foldable No

Column Yes

Accommodations

Lodging back kitchen , living room '01 , bathroom , 3x bedroom , separated toilet

Lodging front studio model '03

Tanks

Stern tanks

Gas oil (l) 18000

Potable water (l) 7000

Dirty water No

Dirty oil No

Foreship tanks

Gas oil (l) 1000

Potable water (l) 1000

Dirty water No

Dirty oil No

Engines, Gearboxes, Generators

Engines

Engine 1

Manufacturer Cummins

Type KTA 38

Year of build 2006

RPM 1800

Gear boxes

Gearbox 1

Manufacturer Masson

Type RA 601

Year of build 2013

Aggregates

Generator 1

Manufacturer Hatz

Type 4 cylinder

Year of build 2012

Power (kVA) 25

Generator 2

Manufacturer Hatz

Type 4 cylinder

Year of build 2009

Power (kVA) 35

Steering gear, Propeller, Bow thruster

Steering gear

Manufacturer De Waal

System hydraulisch

Propeller

Manufacturer Cunial

Spare propeller No

Nozzle ja

Bow thruster

Manufacturer Van Thiem

Type stuurrooster

Construction year 1995

Engine

Manufacturer DAF 320 pk

Year of build 1995

Revision 2015

Equipment, Pumps, Radar

Winches foreship

Manufacturer R&H 380 Volt

Winches stern

Manufacturer R&H 380 Volt

Car crane

Manufacturer 10 --) 14m met afstandbediening

Masts

Masts foreship nieuwe radarmast , telescoopmast op VS

Other nautical equipment

Diverse Compleet , nieuwe piloot & camera's

Levensverhaal, Slogan, Asking price (in €)

Levensverhaal

Improvements Cleaning of the main living quarters MK850 bow thruster: replacement of the tube and shaft New toilet in the living quarters + sealing underneath the shower doors New air conditioning for the forward living area New air conditioning for the wheelhouse New wooden panels for the wheelhouse Fleetguard oil filters, ladder, boat hook, deck-washing hose, rubbing wood, small materials 3 life jackets, small materials Replacement of 2 spotlights at the front Cummins main engine: injectors and turbochargers Slimline 24 V pump Propeller shaft, water lubrication, etc. New Victron Skylla TG24/100A battery charger: supply and installation New Alphatron autopilot Inspection/testing of fire extinguishers + replacement of 2 units Built-in fridge-freezer combination, including €50 installation costs New Victron pure sine wave inverter Reprogramming of VHF radios

Asking price (in €) Price upon request
